Observation by Dean Ashton: Mars 2016

Uploaded by

Dean Ashton OBE

Observer

Dean Ashton

Observed

2016 Jun 06 - 21:55

Uploaded

2018 Mar 02 - 14:00

Objects

Mars

Equipment

500mm Newtonian f/11
Celestron Luminous 2.5x Barlow
Celestron Skyris 618C Camera with IR filter

Exposure

f/33 images captured as 3,600 frames at 60fps

Location

Centro de Observação Astronómica no Algarve https://www.coaa.co.uk (COAA)

Target name

Mars

Title

Mars 2016

About this image

The project to capture the image began with a planned visit to the Centro de Observação Astronómica no Algarve https://www.coaa.co.uk (COAA). Situated in the hills of Poio, near Portimão in Portugal, and facing south, the observatory has a latitude of 37^o11’25”. Mars was low in the sky with an altitude of 29 degrees but higher than in the UK.

To capture this image of Mars we used the 0.5M newtonian telescope at COAA with a Celestron Luminous 2.5x Barlow to give a focal ratio of f/11. Using a Skyris 618 colour camera and IR blocking filter a 10 minute movie at 60 frames per second was recorded.

The image was captured as a 36,017 frame AVI file at 60fps.

The movie was cropped and reduced to the highest quality 3,000 frames using PIPP.

The image was stacked and processed in RegiStax with final processing in PixInsight

Files associated with this observation

Planet Mars 16-06-06 22-55-16_500mm_Newtonian_f11_0.jpg (307.5 kB)
