Observation by Dean Ashton: Jupiter 2017

Uploaded by

Dean Ashton OBE

Observer

Dean Ashton

Observed

2017 May 02 - 21:33

Uploaded

2018 Mar 02 - 12:41

Objects

Jupiter

Equipment

235mm Celestron EdgeHD SCT
f/f33 with Celestron Luminos 2.5x Barlow
ZWO ADC
Celestron SkyRis 618C camera
Celestron CGEM mount

Exposure

f/33 images captured as 3,600 frames at 60fps

Location

St Austell, Cornwall UK

Target name

Jupiter

Title

Jupiter 2017

About this image

iCap application was used for image capture. The exposure was set to 1/60^th second and the camera gain set to give around 70% saturation. Individual AVI files were captured over 60 seconds or 3,600 frames. A total of 6 AVI files were captured to create this image:

The original AVI files were reduced from 3,600 frames to the 2,000 highest quality frames using PIPP.
The PIPP AVI files were stacked using AutoStackert using the highest quality 1,500 frames to create single TIFF images.
The individual images were mapped in WinJupos and stacked.
The final image was processed in PixInsight

Files associated with this observation

Planet Jupiter_2017_05_02_2233_LRGB.jpg (71.6 kB)
