Observation by Mr John William Hughes: Prom on South West Limb

Uploaded by

Mr John William Hughes

Observer

Mr John William Hughes

Observed

2022 Apr 21 - 08:58

Uploaded

2022 Apr 24 - 19:29

Objects

The Sun

Equipment

Lunt 60mm DS TH⍺/B1200CPT
ZWO ASI174mm and tilt adapter
SkyWatcher EQR6-Pro
TeleVue x2.5 Powermate
Hinode Solar Guider

Exposure

Exposure time 25 ms, Gain 189

Location

North Essex, UK

Target name

Prom on South West Limb

Title

Prom on South West Limb

About this image

This GIF represents a time-lapse image of the prom on the South West limb of our Sun on 21 April 2022.

The time-lapse is made up of 107 video files spanning 500 frames each at c40fps. Each video file is separated by 30 seconds. Imaging commenced at 08:58:34 UT and finished at 10:15:25 UT.

I then took each individual video file and stacked this in AutoStakkert3! to construct 107 individual images representing 25% of the best 500 frames.

These 107 images were then processed in PixInsight, aligned in ImPPG and a GIF created in PIPP.

Files associated with this observation


Like this image

Matt Williams, Martin Lewis, Gerard Cauchi

Comments

Martin Lewis, 2022 Apr 26 - 10:24 UTC

Excellent work John. A lot of work to produce that, but interesting to see changes over such an extended period. Well done.

Martin
