Observation by Richard Severn: Total Solar eclipse

Uploaded by

Richard Severn

Observer

Richard Severn

Observed

2026 Aug 12 - 19:28

Uploaded

2026 Aug 15 - 16:45

Objects

The Sun
Eclipse

Equipment

Celestron C11 SCT
ZWO ASI2600MC Pro
Celestron f/6.3 Reducer

Exposure

Approx Shutter=2.875ms Gain=246 (35%)

Location

Sahagun, Spain

Target name

Total Solar eclipse

Title

Total Solar eclipse

About this image

Total solar eclipse high resolution image of chromosphere from Sahagun Spain. Imaged with a Celestron C11 at second contact. A long time ambition to use my C11 during totality.

Files associated with this observation


Like this image

Jeremy Shears, Dawson, Andy Wilson, Dominic Ford, Miguel Araújo, Grant Privett, Mark Fairfax, Graham Winstanley, Mike Foulkes

Comments

Nick James, 2026 Aug 16 - 08:07 UTC

The image is flipped but excellent resolution. The big prominence was really spectacular. It must have been quite an effort to get a C11 and mount down to Spain but it was definitely worth it.

One problem I found with using CMOS astro imaging sensors (such as the IMX571 that you used here) at previous eclipses is that most of them don't have global shutters. That is not a problem if the conditions are calm but if there is any wind vibration the image turns to jelly since each row is exposed at a slightly different time.

Richard Severn, 2026 Aug 16 - 10:31 UTC

Fortunately the wind dropped by totality, but yes the image resembled jelly when I slewed the scope to capture third contact. Perhaps using the reducer to take the C11 from f/10 to f/6.3 helped the capture. We took a ferry from Plymouth to Santander allowing us to use 3 telescopes and 7 cameras in total. Setup alone took 4 hours!
