Observation by Chris Holt: Total solar eclipse, Spain 2026, promine...

Uploaded by

Chris Holt

Observer

Chris Holt

Observed

2026 Aug 12 - 18:31

Uploaded

2026 Aug 17 - 22:19

Objects

The Sun
Eclipse

Equipment
  • Canon EOS 550D
  • Sigma 400 mm f/5.6 prime lens, stopped to f/16
  • Ohnar right angle finder
  • tripod
  • Android tablet controlling camera over USB with OTG cable, running EclipseDroid
Exposure

ISO 100, 1/320 s

Location

Siguenza Castle, Spain

Target name

Total solar eclipse

Title

Total solar eclipse, Spain 2026, prominences and Baily's Beads 2 s before C3

About this image

As part of a large, organised eclipse tour, we had access to the Siguenza Castle parador, including the car park, which offered good views to the west and had been closed to vehicles. Knowing that totality would have a duration of under 99 s, I had prepared a script for EclipseDroid that ran through a series of exposures, beginning 18 s before C2 and ending 18 s after C3. This is one of those exposures. The only processing has been to convert from RAW to 16 bit TIFF in Digital Photo Professional and to crop and convert to JPEG in gimp.

Files associated with this observation
Like this image
Comments
Grant Privett
Grant Privett, 2026 Aug 17 - 22:29 UTC

Does Canon still impose a minimum time between exposures when running via a computer? Used to be 5 seconds - I suppose it avoided a filled image buffer messing up a download.

What was the 18s rationale? Longer and you risk internal damage to the camera?

Chris Holt
Chris Holt, 2026 Aug 18 - 20:39 UTC

Hello Grant, The shooting rate on the 550D, under USB control and writing RAW files, seems in practice to be 0.5 frame/ s. That is with a 64 GB Class 10 SDXC card. The camera has a buffer for six RAW frames, so sets of up to six can be written at 1 frame/ s, particularly if the exposures are short. In testing scripts before going to Spain, requesting exposures at 1 frame/ s starts promisingly but later it does not change to the requested exposures and merely repeats the previous exposure settings for several exposures.

Regarding the 18 s, that came from the example script by Wolfgang Strickling, the author of EclipseDroid. Like him, I had the script display 'Filters off' 20 s before C2. One second later, I had the script turn on Live View mode, to lock up the mirror. Then the first exposure at 18s; although that has a little motion blur - presumably vibration from the mirror moving up. The same sequence was used in reverse for the final exposure, ending of Live View and announcing 'Filters on'.
