Observation by John Hughes:

Uploaded by

Mr John William Hughes

Observer

John Hughes

Observed

2019 May 16 - 08:56

Uploaded

2019 May 16 - 18:08

Objects

The Sun

Equipment

William Optics Z103
Daystar Quark Chromosphere
ZWO ASI174MM
SharpCap
Photoshop

Exposure

10ms with a Gain of 40

Location

North Essex, UK

Target name

Sun

About this image

Having recently seen a couple of gif images on other forums, I wanted to try my hand at doing something similar for AR2741.

This is made up of 24 AVI's of a 1,000 frames each. Best 50% stacked in AutoStakkert2. There is a 4 minute interval between each AVI. Flat frame also generated from a 50% stack of 1,000 frames.

Camera Settings; Exposure 10ms; Gain 40

Equipment William Optics Z103, ZWO ASI174MM and a Daystar Quark.

Software SharpCap for image capture and Photoshop (Levels adjustment applied then two runs with the Unsharp Mask 1) 300% at 1 pixel then 2) 40% at 5 pixels.

Thanks for checking in.

John

Files associated with this observation
