Observation by Geof Lewis: Jupiter 28 June 2019

Uploaded by

Geof Lewis

Observer

Geof Lewis

Observed

2019 Jul 02 - 19:24

Uploaded

2019 Jul 02 - 19:24

Objects

Jupiter

Equipment

C14 XLT
ASI120MM
Astronomic Type2 RGB filters
TV x2 Powermate
ADC

Location

Norfolk

Target name

Jupiter

Title

Jupiter 28 June 2019

About this image

This is the first of the stacked RGB runs used in the previously posted set of 3 images. Whilst the GRS was far from the CM, in line with the BAA challenge, I thought that I'd have a go at measuring the GRS. Using WinJupos to zoom the image, I used its position tool to measure L2 as 306.5 and 321.2 giving a diameter of 14.7 degrees. Using the provided conversion of 1,187 km/deg, I estimated the GRS length as 17,449km.

Files associated with this observation


Like this image

Jeremy Shears, Bill Leatherbarrow, David Basey, Peter Mulligan, Graham Winstanley, Martin Lewis, Andy Wilson, Andrew Dumbleton, Charles Graham Taylor, Jimmy Fraser
