Observation by Martin Lewis: Venus nightside at 1000nm 25th April 202...

Uploaded by

Martin Lewis

Observer

Martin Lewis

Observed

2020 Apr 25 - 18:52

Uploaded

2020 Apr 27 - 19:23

Objects

Venus

Equipment
  • 444mm Dobsonian
  • ASI174MM
  • Edmunds 1000nm filter 25nm bandwidth
Exposure

22mins accumulated exposure time

Location

StAlbans, UK

Target name

Venus

Title

Venus nightside at 1000nm 25th April 2020

About this image

One composite image from several gathered over the last few days attempting to capture surface details on the night-side of Venus using a 1000nm filter with 25nm bandwidth. This particularly photogenic image is 21.6mins of accumulated exposure using an ASI174MM camera at prime focus on my 444mm f4.4mm Newtonian. Imaging has used the ASI camera but also a Chameleon3 camera with the same IMX265 chip as used previously by Anthony Wesley and Phil Miles and reported in the BAA Journal in Oct 2017.

Camera and filter kindly paid for by a Ridley grant from the BAA and without which this would not have been possible.

More hopefully as we near inferior conjunction if the weather cooperates.

Invaluable help in this challenge from Anthony Wesley and Phil Miles in Australia, David Arditti closer to home, and Paul Abel whose suggestion got the ball rolling.

Files associated with this observation
Like this image
Comments
Chris Hooker
Chris Hooker, 2020 Apr 27 - 22:01 UTC

That's a remarkable image, Martin. It looks as if there are a couple of slightly darker patches at lower right around the 4 o'clock position? If they are real they could be surface features: do they appear on any of your other images, or are they just artefacts?

I look forward to seeing more results like this. Well done!

Chris

Martin Lewis
Martin Lewis, 2020 Apr 27 - 22:31 UTC

Thanks Chris.

The larger, elongated, slightly darker region area near the limb at 4 o'clock that is on this image is also at the same position and with a similar shape on a second independent Winjupos combination based on 7x3min videos taken with a different camera in the same session- the Chameleon3 camera I mentioned above. Like with your independent stacks with your Mercury images it gives some assurance that this is a more than likely real feature. I have data from the following night and we'll see if it shows at a similar location on there too.

The Venus bright crescent is not a mask placed onto the image to define the shape- it comes out like that in the processing BTW

Cheers,
Martin

Jeremy Shears
Jeremy Shears, 2020 Apr 28 - 08:58 UTC

This is an amazing image, Martin!

Martin Lewis
Martin Lewis, 2020 Apr 28 - 09:32 UTC

Thanks Jeremy,

This is work in progress and I have more results to post but thought that was an aesthetically pleasing one to start with. Hope to gather more data as the crescent narrows but opportunities depend very much on the weather and time is running out with Venus rapidly approaching inferior conjunction.

Martin
